17A-2
IGNITION
coils
K7J, and 710
17A
REFITTING
When refitting coils or spark plug leads, it is essential
to apply a bead of GRAISSE FLUOREE (part num-
ber 82 00 168 855) with a diameter of 2 mm around
the inner edge of the high voltage caps.
Proceed in the reverse order to removal.
Torque tighten the ignition coil unit mounting
bolts (1.5 daNm).
106640
WARNING
Any damaged spark plug leads must be replaced.
