Logan X90 - Fuel Pump Relay; Injection Locking Relay

17B-2
PETROL INJECTION
Location of components
K7J, and 710
17B
(11) Fuel pump relay
(12) Injection locking relay
107357
(14) Throttle position potentiometer
(13) Idle speed regulator
(15) Injectors
108426
13
15
14
15
8
109211
(8) Upstream oxygen sensor
(7) Oil pressure sensor
(9) Coolant temperature sensor
(10) Engine position and speed sen-
sor
107356
7
9
10
4
5
