17A-5
IGNITION
Spark plugs
K7J or K7M, and 710
17A
Remove:
- the spark plug leads,
- the spark plugs using tool (Ele. 1382).
When refitting coils or spark plug leads, it is essential to
apply a bead of FLUORINE GREASE (part number 82
00 168 855) with a diameter of 2 mm around the inner
edge of the high voltage covers.
107358
Engines Brand Type
K7M
CHAMPION RYCLC87
SAGEM RFN58LZ
K7J
CHAMPION RYCLC87
SAGEM RFN58LZ
Flat skirt with seal
Gap: 0.95 ±±
±±
0.05 mm
Tightening: spark plugs (2.5 to 3 daNm)
106640
