19B-9
EXHAUST
Expansion chamber
K7J or K7M, and 710
19B
REMOVAL
Mount the vehicle on a lift.
Use tool (Mot. 1199-01) to cut the exhaust pipe in the
centre of area to be cut (1).
Use tool (Mot. 1199-01) to cut the exhaust pipe in the
centre of area to be cut (2).
Remove the expansion chamber.
REFITTING
Mount:
- the expansion chamber,
- the sleeves (see 19B, Exhaust, Vehicle Specifi-
cation).
Tighten the sleeve while supporting the exhaust pipe
to ensure correct alignment.
Proceed in the reverse order to removal.
Essential special tooling
Mot. 1199-01 Exhaust pipe cutter
108351
14747
1
108927
2
