13A-8
FUEL SUPPLY
Electric fuel: Checking
K7J or K7M, and 710
13A
Immerse the pipe (2) in a 2 l measuring cylinder.
Disconnect the engine-passenger compartment
electric wiring harness connector (5).
Connect the connector terminal (5) to + battery
feed.
Note the time taken for the measuring cylinder to fill
up.
109174
IMPORTANT
This procedure must be carried out with the igni-
tion off.
109171
2
5
109172
Note:
The minimum pump flow is 60 l/h.
8 15
