11A-40
TOP AND FRONT OF ENGINE
Cylinder head gasket
L90, and K7M, and 710
11A
Fit the rocker cover with a new gasket.
Tightening of the rocker cover:
-Pretighten in order and to torque the rocker cover
mounting bolts (0.2 daNm),
-Torque tighten in order the rocker cover moun-
ting bolts (1 daNm).
Refit:
-the timing belt (see 11A, Top and front of engine,
Timing belt),
-the accessories belt (see 11A, top and front of en-
gine, Accessories belt)
- the exhaust manifold (see 11A, Top and front of
engine, Exhaust manifold).
Torque tighten the multifunction support moun-
ting bolts (2.1 daNm).
Proceed in the reverse order to removal.
Fill up and bleed the cooling circuit (see 19A, Coo-
ling, Draining - Filling the cooling circuit).
10016
DIRECTION ASSISTEE, and AIR CONDITIONING
WARNING
Connect the battery, starting with the positive ter-
minal; carry out the necessary programming (see
80A, Battery, Battery: Removal - Refitting).
1
2
34
56
78
