Replacing the Hard Drive24
3. Using a Phillips screwdriver (not included), remove the screws (x4) from the plastic
brackets on either side of the hard drive.
4. Carefully slide the hard drive back until it is clear of the SATA connector and lift it out of
the DVR.
4.1. DVR SATA connector
4.2. Hard drive SATA ports
#LX400015; r. 1.0/13705/13705; en-US
141
