Using the PC/Mac Client Software
17
1. Show/Hide PTZ Controls: Click this button to hide/show PTZ controls. Click inside the display area
to pan and tilt the camera.
2. Direction Keys: Click to pan and tilt the camera.
3. Speed Slider: Increase or decrease the pan and tilt speed.
4. Zoom
5. Focus
6. Iris
7. Preset: Click + to save the current camera position as a preset. Click — to delete the preset. To go
to a preset, select the number of the preset you would like to go to and then click
.
8. Cruise: Click
to start a cruise. Click to stop the cruise. While cruise is enabled, the camera
will automatically cycle through saved presets.
9. Video Settings: Use the sliders to adjust the video quality settings of the camera.
17.9 Video Playback
Video playback allows you to watch video that has been saved in the DVR’s hard drive.
To playback video:
1. Click the Playback tab.
#LX400015; r. 1.0/13705/13705; en-US
79
