LH040 Series System
Specifications
27
System
Operating System Linux (embedded)
Pentaplex Simultaneous view, record, playback, backup & re-
mote monitoring
Number of Channels
4 channels
Inputs/Ouputs
Video IN 4 x 1Vp-p, CVBS, 75ohms, BNC
Video OUT 1 x BNC
VGA OUT Yes
HDMI Yes
Audio IN
2 Line in (RCA), G.711
Audio OUT 1 line out (RCA), G.711
USB Port 1 at the back for mouse, 1 at the front for firmware
upgrade & USB backup
Alarm IN Alarm IN not supported
Alarm OUT Alarm OUT not supported
Video Output Resolution 1920x1080 (HDMI), 1440x900, 1280x1024,
1024x768, 800x600
PTZ Control RS-485 Pelco D & P Protocol
Display
Live Display 1, 4
Live Display Speed 120 NTSC, 100 PAL
OSD ON/OFF
System Navigation USB mouse, IR remote controller
Motion Area Setting Adjustable grid (30x44) NTSC
Adjustable grid (36x44) PAL
Sensitivity Levels
8
Firmware Upgrade
Automatic over the Internet & via USB device and
network
User Authority By user group
Time Synchronization Auto time sync by NTP server
Recording
Video Compression
H.264
Audio Compression G.711
Recording Resolution
NTSC:
960H: 960x480, 960x240, 480x240
D1 mode: 720x480(D1), 720x240, 360x240
PAL:
960H: 960x576, 960x288, 480x288
D1 mode: 720x576(D1), 720x288, 360x288
#LX400015; r. 1.0/13705/13705; en-US
161
