Basic Setup (LH040 Series)
6
6.5 Step 5: Connect the Monitor
• Connect the included HDMI cable from the
HDMI port to the TV or monitor (recommended)
OR;
• Connect a VGA cable (not included) from the
VGA port to the monitor.
6.6 Step 6: Connect the Power Adapter and Power on the DVR
• Connect the included power adapter to the DC
12V port. Connect the end of the power adapt-
er to a wall socket or a surge protector.
At startup, the system performs a basic system check and runs an initial loading sequence.
After a few moments, the system loads a live display view.
6.7 Step 7: Upgrade Firmware to Latest Version (if Available)
If a firmware upgrade is available, you will be asked to install it once the DVR starts up. It is
required to upgrade your system firmware and client software or mobile apps to the latest
version to enable remote connection to the system.
#LX400015; r. 1.0/13705/13705; en-US
