Replacing the Hard Drive24
If you are installing a 2.5” hard drive:
3.1. Attach the two plastic hard drive brackets to either side of the 3.5” hard drive.
3.2. Place the hard drive in the DVR and slide it gently forward to insert the hard
drive SATA ports into the DVR SATA connector. Ensure that the L-shaped tab
on the mounting bracket slides under the plastic tab in the DVR housing as you
connect the hard drive to the DVR SATA connector. See the diagram below.
#LX400015; r. 1.0/13705/13705; en-US
144
