5. Reinstall the spring toggle bolt in the following order: washer 'N', chain, fender washer 'R', spring
toggle.
6. Insert the spring toggle bolt modified this way with folded wings into the drilled hole and tighten
screw 'H' securely. The chain is permitted only a little slack in the mounted state.
Mounting on a Solid Wall
(Concrete, brick, pumice, etc.)
3. Drill a 6 mm diameter hole about 35 mm deep at the marked spot.
4. Insert wall plug 'K' into the drilled hole and screw in eyebolt 'J'.
5. Guide the chain through the eyebolt and screw the chain with screw 'E' and hex nut 'F' as shown.
The chain is permitted only a little slack in the mounted state.
Mounting on Wooden Walls
3. Screw eyebolt 'L' into wall at the marked spot (pre-drill if necessary).
4. Guide the chain through the eyebolt and screw the chain with screw 'E' and hex nut 'F' as shown.
The chain is permitted only a little slack in the mounted state.
