Technical Manual LÖWEN Dart HB8
01/2019 12
3.
Installation and Initial Start-up
3.1 Installation
After removal of the packaging, the machine must be prepared as follows:
1. Open the electronics compartment cover.
2. Remove the thumb screws and the mains cable from the cashbox, and lay them out in the electronics
compartment.
Top cabinet, upper cabinet
Game select console cover
Thumb screws
Electronics compartment cover
Coin door
Cashbox door
