Technical Manual LÖWEN Dart HB8
01/2019 75
7.2.7 t07 - SEL brN: Burn-in Test
This test is run to test all LEDs, lamps, and their associated circuity.
1. Press [TEST] button on the controller board.
tSt appears in the TEMP SCORE display.
2. Press [OPTIONS II] button to confirm.
3. Press [GAMES] or [OPTIONS I] until SEL brN appears in player 1 – 2 display, and t07 in the TEMP
SCORE display.
4. Press [OPTIONS II] to start the test.
All Cricket LEDs are lit. They will be switched off and on again one after the other.
The game select LEDs will be switched on and off one after the other.
The “DON’T THROW” and “THROW” lamps as well as [PLAYER CHANGE] button will be switched on
and off one after the other.
5. Press [PLAYER CHANGE] button. All LEDs and lamps are lit.
6. Press [PLAYER CHANGE] button again. All LEDs and lamps are flashing.
7. Press [PLAYER CHANGE] button once again to exit the test.
7.2.8 t08 - SEL Ir: Infrared Sensor Test
Testing the infrared sensor.
1. Press [TEST] button on the controller board.
tSt appears in TEMP SCORE display.
2. Press [OPTIONS II] button to confirm.
3. Press [GAMES] or [OPTIONS I] button until SEL Ir appears in player 1 – 2 display, and t08 in TEMP
SCORE display.
4. Press [OPTIONS II] button to start the test.
5. Place yourself directly in front of the dart machine. The “DON’T THROW” lamp is lit. If you move away
from the machine, the “DON’T THROW” lamp goes out and the “THROW” lamp is lit.
6. Press [PLAYER CHANGE] button to exit the test.
NOTICE Adjust sensivity in such a way that the “DON’T THROW” lamp is lit when you
near the machine at arm’s length. The potentiometer is located in the upper
cabinet, just behind the infrared sensor. Please compare chapter 0 3.4.1
Adjustment Infrared Sensor.
