67
The "A" figures to the left show locations with Colorline set at the
factory level of 70 percent. The "B" figures on the right show the same
locations with Colorline increased to 84 percent. In Figure 1B, no fish
are near the left structure, but the right structure shows fish holding
next to the structure.
Colorline
Muddy
bottom
Hard
bottom
Muddy
bottom
Fish nea
r
structure
Hard
bottom
Hard
structure
Colorline
Colorline
Fig. 2A
Fig. 3A
Fig. 2B
Fig. 3B
Fig. 1A
Fig. 1B
