Appendix I – Error Messages
104
Sensor Input Errors
E31 : Sensor Input Limit (+ve)
The ADC input is greater than the maximum measurable input
level. (+2.5V)
E32 : Sensor Input Limit (-ve)
The ADC input is lower than the minimum measurable input level
(-2.5V)
E33 : Sensor Input Over-range
The detected sensor input is greater than 200.0% Saturation
E34 : Sensor Input Under-range
The detected sensor input current is less than the 0% saturation
current
E35 : Temperature Sensor Fault
The temperature sensor is reading open or closed circuit, due in
most cases to a damaged sensing element or incorrect wiring.
When this error occurs the unit will use the “Fixed Temp” setting
for compensation purposes to avoid excess compensation.
E36 : Temperature Compensation Outside Limits
The temperature input is outside the operating temperature limits
for the attached probe.
E37 : Temperature Input Greater than Maximum limit
(Dependant on Sensor Type)
E38 : Temperature Input Less than minimum limit
(Dependant on Sensor Type)
