LTH MOD53 - Page 40

6 Main Display
39
Ø
ØØ
Ø ×
××
×
60.0
60.060.0
60.0
%
Output A : 12.76mA
Sensor + Current Output A (if fitted)
Ø
ØØ
Ø ×
××
×
60.0
60.060.0
60.0
%
Output B : 12.76mA
Sensor + Current Output B (if fitted)
Ø
ØØ
Ø ×
××
×
60.0
60.060.0
60.0
%
Zero Cal
Zero (0% Saturation) Calibration
(Available when access parameter set in
“Calibration” menu).
Ø
ØØ
Ø ×
××
×
60.0
60.060.0
60.0
%
Span Cal.
Span (100% Saturation) Calibration
(Available when access parameter is set in
the “Calibration” menu).
Ø
ØØ
Ø ×
××
×
1.00
1.00 1.00
1.00
Atm
Calib Pressure
When “Span Calibration” is complete the
calibration pressure is displayed. (The
Calibration Pressure can be set manually in
the “Calibration” menu).
Selecting the parameter and pressing the “ENTER” key (provided that no error
messages are present) will set the default secondary parameter. This is the
default parameter that is displayed on the bottom line, when the unit is switched
on, or as a result of returning to the normal display mode.
