LTH MOD53 - Page 93

Appendix D – Customer Setup
92
Set Points 2 - 4
SP2 Source
SP2 Trigger
SP2 Level (Latch High)
SP2 Latch Low
SP2 Mode
SP2 Dose Alarm
SP2 Alarm Time (mm:ss)
SP2 Delay (mm:ss)
SP2 Hysteresis
(% of SP Level)
SP2 Cycle Time (mm:ss)
SP2 Proportional Band
(% of range)
SP3 Source
SP3 Trigger
SP3 Level (Latch High)
SP3 Latch Low
SP3 Mode
SP3 Dose Alarm
SP3 Alarm Time (mm:ss)
SP3 Delay (mm:ss)
SP3 Hysteresis (% of SP)
SP3 Cycle Time (mm:ss)
SP3 Proportional Band
(% of range)
SP4 Alarm Trigger
Cleaning
Duration (mm:ss)
Interval (hh:ss)
Mode
Recovery (mm:ss)
Delay
