SPECIFICATIONS
MODEL 600 HO E-TEC
DIMENSIONS AND WEIGHT
Vehicle overall length 347 cm (136.6 in)
49 Ranger 110.5 cm (43.5 in)
Vehicle overall width
49 Ranger Touring 118 cm (46.46 in)
Vehicle overall height 147 cm (57.874 in)
49 Ranger 257 kg (566.6 lb)
Dry weight
49 Ranger Touring 267 kg (588.6 lb)
49 Ranger 921 mm ± 21 mm (36.26 in ± .827 in)
Ski stance
49 Ranger Touring 996 mm ± 21 mm (39.213 in ± .827 in)
Ski width 188 mm (7.402 in)
(1)
Refer to
INJECTION OIL
subsection for detaile d i nformation.
(2)
Measure gap between slider shoe and bottom inside track when exerting a
downward pull to the track.
(3)
NOTICE Do not attempt to adjust gap on this spark plug.
______________
139
