SPECIFICATIONS
90 0 ACE Models
MODEL 49 RANGER 900 ACE
ENGINE
Engine type
Rotax 903, liquid cooled, 4-stroke,
D.O.H.C., dry sump
Cylinders
3
Displacement 899 cm³ (54.9 in³)
Bore 74 mm (2.9 in)
Stroke 69.7 mm (2.74 in)
Maximum horsepower RPM 7250 RPM
Exhaust sy stem Single front pipe, baffle muffler
Engine oil
(P/N ) ( P/N 619 590 114) or SAE 0W 40
API SM synthetic oil
Engine oil capacity Oil change, 3.3 L (3.5 qt (U.S. liq.))
Engine coolant
Ethyl glycol/water mix (50%
coolant, 50% distilled water).
Use BRP LONG LIFE ANTIFREEZE(F)
(P/N 619 590 204)
or coolant specifically
designed for aluminum engines
FUEL SYSTEM
Fuel injection system Multi point EFI, 46 mm throttle body
Recommended fuel
Regular unleaded (fuel containing MAXIMUM
10% ethanol)
Minimum o ctane rating. Refer to
FUEL REQUIREMENTS
95 RON (fuel which may contain up to
10% MAX ethanol)
Fuel tank capacity 34 L (8.98 U.S. gal.)
ELECTRICAL SYSTEM
Lightning system output 644 Watts @ 6000 RPM
Headlights bulb HI/LOW beam Spark plug 2 x 60/55 Watts (H-4)
Taillight bulb 2.6 W / 139m W LED
Type NGK MR8BI-8
Spark Plug
Gap .8 mm (.031 in)
140
