SPECIFICATIONS
MODEL 49 RANGER 900 ACE
ELECTRICAL SYSTEM (cont'd)
FA: Main 40 A
F1: Ignition coils, fuel injectors,
fuel pump, starter solenoid
10 A
F2: Accessories 20 A
F3: Electro mechanical reverse 20 A
F4: S tart clock, cooling fan 10 A
F5: Headlights, taillight, brake
light
20 A
F6: ECM, gauge, CAPS 10 A
R1: Main relay Fuses F1, F3 and F6
R2: Lighting relay Fuse F5
Fuses and relays
R3: Accessory relay Fuse F2
DRIVE SYSTEM
Drive pulley type eDrive II
Driven pulley type QRS (short shaft)
Engagement 2200 RPM
Type
(P/N )
(P/N 619 590 098)
Chaincase oil
Capacity 500 ml (16.9 U.S. oz)
Drive Belt Part Number
417 300 383
(1)
Small sprocket number of teeth
21
49 Ranger with 59mm track profile
51
Large sprocket number
of teeth
49 Ranger with 49mm track profile
49
Drive sprocket number of teeth
8
Track nominal width 40.6 cm (15.984 in)
Track nominal length 414.1 cm (163.031 in)
Track profile height
39 mm (1.535 in) OR
59 mm (2.323 in)
Deflection 40 mm - 50 mm (1.575 in - 1.969 in)
Force without force 0 kg (0 lb)
Deflection 60 mm - 70 mm (2.362 in - 2.756 in)
Track tension
Force
(1)
7.3 kg (16 lb)
Track alignment
Equal distance between edges of track
guides and slider shoes
______________
141
