SPECIFICATIONS
MODEL 49 RANGER 900 ACE
BRAKE SYSTEM
Brake system type Brembo with braided stainless-steel brake line
Brake fluid DOT 4
SUSPENSION
Front suspension A-LFS+
Front shock HPG 36
49 Ranger except 59mm track
profile
190 mm (7.48 in)
Front suspension max.
travel
49 Ranger with 59mm track profile 210 mm (8.268 in)
Rear suspension PPS²-4100-DS-A
Center shock HPG 36
Rear shock HPG 36
Rear suspension max.
travel
390 mm (15.354 in)
WEIGHT AND DIMENSIONS
49 Ranger except 59mm track
profile
278 kg (613 lb)
Dry weight
49 Ranger with 59mm track profile 281 kg (619.5 lb)
Vehicle overall length 347 cm (136.6 in)
Vehicle overall width 118 cm (46.46 in)
Vehicle overall height 147 cm (57.874 in)
Ski stance 996 m m ± 21 mm (39.213 in ± .827 in)
(1)
Drive belt height must be adjusted every time a new drive belt is installed.
Confirm drive belt part number application with an authorized LYNX dealer.
142
