User Guide52 DCP-200
Main MIDI Transmit Channel (C#2)
Pressing the MIDI Transmit Channel key will set the Data Control knob to increase or decrease the Main MIDI
Transmit channel number.
To change the Main MIDI Transmit Channel:
 PresstheVoice/FunctionbuttontoenterEditMode.
Press the MIDI Transmit Channel Key (C#2)
   TheLEDDisplaywillmomentarilyshow:

Use the Data Control knob to select the desired Main MIDI Transmit
Channel.
Note that the MIDI channels used for the Split and Layer voices are
relative to the Main MIDI Transmit Channel, in the following way:
Split Voice Transmit Channel = Main MIDI Transmit Channel +1
Layer Voice Transmit Channel = Main MIDI Transmit Channel +2
Reverb
Song
RECORD
Data Control
[Assignable]
Metronome
Voice / —
Function
PNo
MASTER VOLUME
Reverb
Song
RECORD
Data Control
[Assignable]
Metronome
Voice / —
Function
off
C0 C1 C2
C#2
Reverb
Song
RECORD
Data Control
[Assignable]
Metronome
Voice / —
Function
6
1
3
2
