OPERATOR’S STATION
Form # 169017 32 Issue – June 2008
CAB FORWARD/ENGINE RUNNING/HEADER DISENGAGED
(Scroll Through Display with CDM Switch or GSL Switch)
DISPLAY (Lower or Upper Line) DESCRIPTION
#####.# ENGINE HRS
Total Engine Operating Time.
#####.# HEADER HRS
Total Header Operating Time.
###.# SUB ACRES
###.# SUB HECTARES (If Metric)
Area Cut Since Last Reset. To Reset, Display SUB
ACRES On Lower Line And Hold Down Program Switch
Until Display Resets (5-7 Seconds).
###### TOTAL ACRES
###### TOTAL HECT (If Metric).
Total Area Cut By Machine.
##.# HEADER HEIGHT
Distance Setting (00.0-10.0) Between Cutterbar &
Ground.
##.# HEADER ANGLE
Angle Setting (00.0-10.0) Header Relative to Ground.
##.# L FLOAT R ##.#
Float Setting (0.0-9.9).
##.# VOLTS
Engine Electrical System Operating Voltage.
SCROLL (Lower Line)
Displays Above Items After 2-3 Seconds. Press SELECT
to cancel.
