OPERATOR’S STATION
Form 169017 33 Issue – June 2008
CAB FORWARD/ENGINE RUNNING/HEADER ENGAGED
AUGER HEADER
(Scroll Through Display with CDM Switch or GSL Switch)
DISPLAY (Lower or Upper Line) DESCRIPTION
#####.# ENGINE HRS
Total Engine Operating Time.
#####.# HEADER HRS
Total Header Operating Time.
##.# ACRES/HOUR
##.# HECTARES/HOUR (If Metric)
Actual Cutting Rate In Acres (Hectares)/Hour.
###.# SUB ACRES
###.# SUB HECTARES (If Metric)
Area Cut Since Last Reset.
###### TOTAL ACRES
###### TOTAL HECT
(If Metric)
Total Area Cut By Machine.
##.## REEL RPM
##.## REEL SENSOR (If Sensor Disabled)
Reel Rotational Speed.
##.# AUGER SPEED
Auger Rotational Speed (0.0-10.0).
#### KNIFE SPEED
#### KNIFE SENSOR (If Sensor Disabled)
Knife Speed In Strokes Per Minute.
##.# HEADER HEIGHT
##.# HEADER SENSOR (If Sensor Disabled)
Distance Setting (00.0-10.0) Between Cutterbar &
Ground.
##.# HEADER ANGLE
##.# HEADER SENSOR (If Sensor Disabled)
Angle Setting (00.0-10.0) Header Relative To
Ground.
##.# L FLOAT R ##.#
FLOAT SENS DISABLED (If Sensor Disabled)
Left And Right Float Setting (0.0-9.9).
LOAD|■■■■■■■■■■■■
Bar Graph Representing Hydraulic Operating
Pressure. If sensor disabled, LOAD does not
display. See Note below.
##.# VOLTS
Engine Electrical System Operating Voltage.
SCROLL (Lower Line)
Displays Sub-Menu After 2-3 Seconds. Press
SELECT to cancel.
NOTE: The load sensor is factory installed on M200 (optional for M150) to monitor knife/conditioner circuit
pressure. To monitor reel circuit pressure, relocate sensor as per Instruction 169031 which is available
through your dealer.
(Scroll Through Sub-Menu Display with CDM Switch)
SCROLL SUB-MENU (Lower Line Only)
#### KNIFE SPEED
##.# HEADER HEIGHT
LOAD|■■■■■■■■■■■■
##.## REEL RPM
##.# AUGER SPEED
KNIFE SPD OVERLOAD (Lower Line)
Knife Speed Drops Below Programmed Set-Point.
