C. A/B Pushbutton Select Functions (Standard)
Type-A selector sequence : A → B → A → B …
Type-B selector sequence : Off → A → B → Off → A → B …
Type-C selector sequence : A → B → A+B → A → B → A+B …
Type-D selector sequence : Off → A → B → A+B → Off → A → B → A+B …
NO PB1 PB2 PB3 PB4 PB5 PB6 PB7 PB8 PB9 PB10 PB11 PB12
029 A/1.2
030 B/1.2
031 C/1.2
032 D/1.2
033 A/3.4
034 B/3.4
035 C/3.4
036 D/3.4
037 A/1.2 A/3.4
038 A/1.2 B/3.4
039 A/1.2 C/3.4
040 A/1.2 D/3.4
041 B/1.2 B/3.4
042 B/1.2 C/3.4
043 B/1.2 D/3.4
044 C/1.2 C/3.4
045 C/1.2 D/3.4
046 D/1.2 D/3.4
047 A/1.2
048 B/1.2
049 C/1.2
050 D/1.2
