C. A/B Pushbutton Select Functions (Standard)
Type-A selector sequence : A → B → A → B …
Type-B selector sequence : Off → A → B → Off → A → B …
Type-C selector sequence : A → B → A+B → A → B → A+B …
Type-D selector sequence : Off → A → B → A+B → Off → A → B → A+B …
NO PB1 PB2 PB3 PB4 PB5 PB6 PB7 PB8 PB9 PB10 PB11 PB12
025 A/1.2
026 B/1.2
027 C/1.2
028 D/1.2
029 A/1.2
030 B/1.2
031 C/1.2
032 D/1.2
033 A/1.2
034 B/1.2
035 C/1.2
036 D/1.2
037 A/1.2
038 B/1.2
039 C/1.2
040 D/1.2
041 A/1.2
042 B/1.2
043 C/1.2
044 D/1.2
045 A/1.2
046 B/1.2
