Special tools
186
34
1
2
3
4
5
6
35
36
Fig. no. Designation Item number
34 Measuring combination, consisting of:
(1) Dial gauge 08.71000−1205
(2) Tracer pin for dial gauge 80.99605−0197
(3) Dial gauge holder 80.99605−0179
(4) Contact pin 80.99605−0180
(5) Dial gauge holder 80.99605−6006
(6) Dial gauge holder 80.99605−0172
35 Press−on measuring plate 80.99605−0195
36 Fitting sleeves 51.91701−0247
