4 Product overview
4.1 Application
The M&C ultra-low cooler EC-30C is used in the gas analysis technique to reduce the dew
point of humid sample gases and to provide a stable and very low dew point. This elimi-
nates condensate built-up and aerosol formation in the analyzer.
Due to the extremely stable and low gas dew point, there are no water vapor cross-sensi-
tivity and volumetric errors.
Sample gas IN
Condensate OUT
Test gas IN
Fig. 1: Application example of the EC-30C
1 Gas sample probe SP2000-H 2 Electrically heated sample line 4M4/6
3 Ultra-low cooler EC-30C 4 3-way ball valve 3L/PV-1
5 Filter 6 Bellows pump MP-F
7 Aerosol filter CLF -5/W optional depend-
ing on application
8 Analyzer, e.g. PMA1000
9 Flow meter FM40, 25-250 Nl/h 10 Option: 4.peristaltic pump with solenoid valve
(heat exchanger purging)
11 Option: three SR25.2 peristaltic pumps
(condensate removal)
