Options
Part-No.: 01 P 9145 Peristaltic pump SR25.2, to mount into the EC-30C (See
spare parts for SR25.2 on page 70 chapter ‘12.3
Spare parts and consumables’ )
Part-No.: 03 F 3000 Aerosol-Filter CLF-5: External mounting in the outlet of
an ultra low gas cooler EC-30C when sample tends to
form aerosols.
Technical data see data sheet 7.7 Fluid particle filter
CLF-5
Part-No.: 02 K 9700 (a)* Heat-exchanger purging: 4. peristaltic pump with
solenoid valve
Part-No.: 03 E 1001 LA 1S humidity sensor, 4 m (13.12 ft) cable with cable
breakage detection
Part-No.: 03 E 3500 FA 20 (Flow sensor with 0.45 m [1.48 ft] cable)
Part-No.: 02 K 9710 FM 40 (Flow meter, 25-250 Nl/h)
* (a)Addition to the part number for EC-30C with 115 V
5.1 Max. possible water vapor dew point input [°C] / [°F]
This table shows the max. possible water vapor dew point input (°C) / (°F) depending on
the incoming gas temperature and the flow rate.
These values correspond to the maximum cooling capacity of 130 kJ/h. The maximum
possible water vapor dew point input (°C) / (°F) indicated must not be exceeded.
Incoming gas temperature in °C (°F)
Gas flow [l/h] 70
(158 °F)
90
(194 °F)
120
(248 °F)
150
(302 °F)
180
(356 °F)
90 70
(158 °F)
70
(158 °F)
69
(156.2 °F)
68
(154.4 °F)
67
(152.6 °F)
110 68
(154.4 °F)
67
(152.6 °F)
66
(150.8 °F)
65
(149 °F)
63
(145.4 °F)
130 65
(149 °F)
64
(147.2 °F)
63
(145.4 °F)
61
(141.8 °F)
59
(138.2 °F)
150 62
(143.6 °F)
61
(141.8 °F)
59
(138.2 °F)
58
(136.4 °F)
56
(132.8 °F)
170 59
(138.2 °F)
58
(136.4 °F)
56
(132.8 °F)
55
(131 °F)
53
(127.4 ° F)
190 57
(134.6 °F)
56
(132.8 °F)
54
(129.2 °F)
52
(125.6 °F)
50
(122 °F)
210 55
(131 °F)
54
(129.2 °F)
52
(125.6 °F)
49
(120.2 °F)
46
(114.8 ° F)
230 53
(127.4 ° F)
52
(125.6 °F)
49
(120.2 °F)
47
(116.6 °F)
43
(109.4 °F)
250 52
(125.6 °F)
50
(122 °F)
47
(116.6 °F)
44
(111.2 ° F )
41
(105.8 °F)
