14 EC-30C | 1.00.02 +49 2102 935 888 www.mc-techgroup.com
5 Technical Data
Series EC
©
Version EC-30C
Part No.: 02 K 6100 (a)*
Gas connection DN 4/6 tube connector
Condensate connections 3x tube connector GL25-12 mm
Material of sample contacting
parts
Duran Glass, PTFE, PVDF
Single stream, gas flow rate 90 Nl/h – 250 Nl/h
Gas pressure max. 3 bar abs.
Ambient temperature +5 °C to +45 °C (+41 °F to +113 °F)
Storage temperature -20 °C to +60 °C (~-4 °F to +140 °F)
Sample outlet dew point -20 °C to -30 °C (default -30 °C) (~-4 °F to ~-22 °F, default
~-22 °F)
Sample inlet temperature max. 180 °C (+356 °F)
Water vapor dew point input max. 70 °C (+158 °F)
Cooling capacity max. 130 kJ/h** (at given input conditions)
Main power connection /
Power consumption
230 V, 50 Hz, 380 VA
or* Part-No. …-a=115 V, 60 Hz, 380 VA
Start up time < 60 min
Dead space approx. 160 ml (5.41 fl. oz)
∆P at 250 Nl/h flow rate 5 mbar
Electrical connection 2.5 mm
2
(0.0039 in
2
) terminals, cable glands PG (1 x 12
mm, 2 x 16 mm, 2 x 20 mm)
mA-output 0 - 20 mA / 4 - 20 mA, max. 500 Ohm load (including
cable resistance),
Relay output alarm 1 changeover contact: 230 V AC 3 A, 24 V DC 3 A
alarm: COM & NC closed
No alarm: COM & NO closed
Relay output warning 1 NO contact, 24 V (AC/DC), 0.5 A
warning: open
Relay output freezer units I and
II
1 NO contact, 24 V (AC/DC), 0.5 A
unit I on: closed
unit II on: open
Case protection IP20, EN 60529
Electrical equipment standard EN 61010
Method of mounting 19" rack or wall mount
Case color RAL 9003
Dimension (w x h x d) 84 HP x 8U (with connections) x 360 mm (14.17“)
Weight 39.34 kg (86.73 lbs)
* (a)Addition to the part number for EC-30C with 115 V
** For the given input conditions, please have a look at the table on page 15 chapter ‘5.1 Max.
possible water vapor dew point input [°C] / [°F]’ .
