7.9.1 Parameter settings
The parameters displayed on the screens can be adjusted within a defined parameter
range.
You can set the following parameters:
Parameter Parameter range Default value
Service interval
Off (0 days),
1-1095 Tage
365 days
mA-output
(power range)
0-20 mA,
4-20 mA
4-20 mA
mA-output
(correlated temperature range)
Min.: -40 °C to -10 °C
(Min: ~-40 °F to 14 °F)
Max.: +10 °C to +60 °C
(Max: +50 °F to 140 °F)
-30 °C to +30 °C
(~-22 °F to +86 °F)
Required deep-cooling temperature
-20 °C to -30 °C
(~-4 to °F to ~-22 °F)
-30 °C (~-22 °F)
Date
[Day, Month, Year]
Day: 01 to 31
Month: 01 to 12
Year: 15 to 99
01.01.16
Time
[Hour, Minute, Second]
Hour: 00 to 23
Minute: 00 to 59
Second: 00 to 59
12:00:00
To reach the program level for setting the parameters please start from the corresponding
parameter screen and press the PRG button.
PRG
ESC
Fig. 25: How to reach the parameter settings
