70 EC-30C | 1.00.02 +49 2102 935 888 www.mc-techgroup.com
12.3 Spare parts and consumables
The replacement interval for spare parts and consumables depends on the specific oper-
ating condition of the analyzer. The quantities recommended in the following table are
based on experience. Your replacement intervals will be based on your operating
conditions.
The product label with the serial number is located on the back of the EC-30C.
Type and name of the product
(C) Consumables
(R) recommended spare parts
(S) spare parts
recommended amount
based on number of
years of operation [years]
Part-No. Name C/R/S 1 2 3
90 K 6215 0-20 V Module R - - -
90 K 6210 Main electronics (Var 1) R - - -
90 K 6200 Power supply electronics (Var 1) R - - -
90 K 6205 Rectifier electronics (Var 1) R - - -
90 K 6220 Main adapter R - - -
EE 02710005 Rectifier capacitor R - - -
90 K 6265 Converter R - - -
90 K 6225 Fuse set* EC-30C 230 V R - - -
90 K 6225a Fuse set* EC-30C 115 V R - - -
90 K 1002 Temperature sensor pre-cooling unit PCU R - - -
90 K 0040x Temperature sensor deep-cooling unit DCU R - - -
93 K 0047 Peltier element R - - -
90 K 6245 O-ring set** Silicone EC-30C R - - -
90 K 1014 Cooling aggregate 230 V R - - -
90 K 1014a Cooling aggregate 115 V R - - -
90 K 1055 Starting capacitor: compressor 230 V: 80 µF R - 1 1
90 K 1060 Starting capacitor: compressor 115 V: 160 µF R - 1 1
90 K 6001 Heat exchanger glass DCU R 1 1 1
02 K 9105 Heat exchanger glass PCU R 1 1 1
90 K 6003 Heat exchanger PVDF DCU R 1 1 1
02 K 9300 Heat exchanger PVDF PCU R 1 1 1
90 K 0115 Heat conductivity paste (50 g)***
90 K 6040 Solenoid valve 230 V R - - -
90 K 6041 Solenoid valve 115 V R - - -
90 K 0042 Fan 230 V R - - -
90 K 0042a Fan 115 V R - - -
EZ 0024 Display controller TCU R - - -
91 B 8600 Key-pad R - - -
