Manitou AETJ 43 User Manual

13
GENERAL CHARACTERISTICS AND SAFETY
547379EN
00 (08/03/2017)
00
00.2 GENERAL CHARACTERISTICS AND SPECIFICATIONS
00.2.1 CHARACTERISTICS
Designation 120 AETJL 150 AETJC 150 AETJC 3D 150 AETJL 170 AETJL AETJ 43 AETJ 43 3D AETJ 49
Unladen weight of carriage
5050 kg
(11,133 lbs)
6700 kg
(14,771 lbs)
6760 kg
(14,904 lbs)
5910 kg
(13,030 lbs)
6910 kg
(15,234 lbs)
7100 kg
(15,653 lbs)
7160 kg
(15,785 lbs)
7105 kg
(15,684 lbs)
Unladen pneumatic
load
FRONT
1185 kg
(2,613 lbs)
1465 kg
(3,230 lbs)
1465 kg
(3,230 lbs)
1240 kg
(2,734 lbs)
1534 kg
(3,389 lbs)
- -
1555 kg
(3,428 lbs)
REAR
1340 kg
(2,954 lbs)
1885 kg
(4,156 lbs)
1885 kg
(4,156 lbs)
1715 kg
(3,781 lbs)
1921 kg
(4,325 lbs)
- -
1992.5 kg
(4,393 lbs)
Nominal capacity
(2 people)
200 kg
(441 lbs)
200 kg
(441 lbs)
200 kg
(441 lbs)
230 kg
(507 lbs)
200 kg
(441 lbs)
227 kg
(500 lbs)
227 kg
(500 lbs)
227 kg
(500 lbs)
00.2.2 LUBRICANTS AND FUEL
Designation Type Quantity
Hydraulic tank MANITOU ISO VG 46 Hydraulic oil
18 
(4.76 US gallons)
Wheel motor (each)
Turret rotation motor
SHELL SPIRAX A90 oil
0.8 
(0.21 US gallons)
1.5 
(0.40 US gallons)
General greasing SHELL RETINAX HD grease -
Greasing of turret crown of
bearing track
Grease SHELL ALVANIA EP LF 2 -
Lubrication of turret crown
gear teeth
SHELL MALLEUS GL 205 oil -
