Manitou AETJ 43 User Manual

ELECTRICITY
96
80
547379EN
80 (08/03/2017)
VARIABLE SPEED CONTROLLER HARNESS
- ITEM 6
According to
installation
114
115
116
105
110
113
103
101
112
117
100
127
107
235
108
109
118
119
106
106
B+
B
-
R
S
F2
F1
A
F1
KM1
KM2KM3
103
110
105
132
132
100
101
102
106
130
106
106
235
1
45
3
2
123
456
123
7
456
1112 10
89
103
121
VARIABLE SPEED
HARNESS
678397 - C
Ref. 6
To complete
base box
Ref. 5
To
variable speed drive
fuses board
To
variable speed drive
drive board
To right-hand
battery + terminal
To battery cut-out
Pos. Wire Colour
1 115 brown
2 Spare
3 116 white
4 Spare
5 Spare
Shield. 114 Green
Pos.
1
2
3
4
5
6
Wire
spare
spare
127
spare
113
112
Pos.
1
2
3
4
5
6
7
8
9
10
11
12
Wire
106
119
117
109
108
118
107
102
130
spare
121
spare
To charger
A
B
