Manitou AETJ 43 User Manual

73
ELECTRICITY
80
547379EN
80 (08/03/2017)
ELECTRICITY
80.1 ELECTRICAL SCHEMATIC DIAGRAMS
WARNING
Diagram 1
st
VERSION
Access platform tted with an overload sensor harness comprising:
a Deutsch connector with........................................................... 8-way
SQ5a SQ5b
SQ5a SQ5b
WARNING
Diagram 2
nd
VERSION
Access platform tted with an overload sensor harness comprising:
a Deutsch connector with........................................................... 3-way
SQ5a SQ5b
SQ5a SQ5b
