ELECTRICITY
80
547379EN
80 (08/03/2017)
BATTERY CHARGE INDICATOR/HOUR METER
Description
- Screen (1, 080 - 104).
- Battery charge indicator (2, 080 - 104).
- Hour meter and variable speed controller fault display screen (3,
080 - 104).
- Connection socket (1, 080 - 105).
Operation (see instruction manual).
Connection
PIN Signal
1
Free
2 0V (masse)
3 +12V (back-lit)
4
+12V (power supply)
5 CAN_H
6 CAN_L
Error messages variable speed controller (680.1 ELECTRICAL
SCHEMATIC DIAGRAMS, 5 73)
Maintenance
SEVCON
h
100%0%
P
T
80 - 104
1
2
3
1 2 3
4 5 6
80 - 105
1
