Additional pages GMK 4100 3 112 331 en 9
12.12.2008
Integrated heavy
load lattice exten-
sion: ISS-A or ISS-
B
With ISS-A, part A is folded on the main boom; à Lattice extension operating
instructions GMK 4100; integrated heavy load lattice extension (ISS)
.
All the axle loads in the following table apply for a 40 t hook block (weight
550 kg (1,215 lbs)) reeved on the lattice extension.
Coun-
ter-
weight
in t
(lbs)
Telescoping
Telescopic section
I-II-III-IV-V
Main
boom
angle
(°)
Lattice
exten-
sion incli-
nation
(°)
Main
boom
position
1)
Maximum axle load
2)
in t
(x 1000 lbs)
front rear
4,1
(9 000)
0.5 - 0 - 0 - 0 - 0 20 – 40 0 – 20 front
12,5
(27,5)
14,0
(30,8)
Not permitted! rear
6,3
(13 800)
0.5 - 0.5 - 0 - 0 - 0 20 – 45 0 – 20 front
15,5
(34,2)
15,0
(33,1)
Not permitted! rear
8,5
(18 700)
0.5 - 0.5 - 0.5 - 0 - 0 25 – 45 0 – 20 front
16,5
(36,4)
15,0
(33,1)
0 - 0 - 0 - 0 - 0 78 – 80 20 – 40 rear
9,0
(19,9)
16,5
(36,4)
10,7
(23 700)
0.5 - 0.5 - 0.5 - 0 - 0 20 – 40 0 – 20 front
15,5
(34,2)
16,0
(35,4)
0 - 0 - 0 - 0 - 0 75 – 80 20 – 40 rear
10,0
(22,0)
17,0
(37,5)
12,9
(28 400)
0.5 - 0.5 - 0.5 - 0 - 0 20 – 35 0 – 20 front
14,0
(30,8)
17,0
(37,5)
0 - 0 - 0 - 0 - 0 75 – 80 20 – 40 rear
11,0
(24,2)
17,0
(37,5)
15,1
(33 200)
0.5 - 0.5 - 0.5 - 0 - 0 20 – 30 0 – 20 front
12,0
(26,4)
18,5
(40,8)
0 - 0 - 0 - 0 - 0 70 – 80 20 – 40 rear
12,5
(27,5)
18,5
(40,8)
