Swing-away lattice
3.3 Rigging work checklists
3 - 26 3 112 441 en Lattice extension operating instructions
GMK 4100/4100-L/5095
11.01.2008
30. Only applies to the derricking swing-away lattice:
– Move the hydraulic hoses into the main boom operation position;
à p. 3 - 34.
31. Check the transport condition of the swing-away lattice;
à Transport
condition with folded swing-away lattice
, p. 3 - 30.
