NAC Devices Currents (All currents are in ampere)
The total currents of each loop must <= 2A
FW961R/FW961W
LED Horn/Strobe
×
0.0000045
0.117
FW971R/FW971W
Horn
×
0.0000045
0.017
FW981R/FW981W
LED Strobe Light
×
0.0000045
0.075
FW962R/FW962W
(@130 cd setting)
Multi-candela Horn Strobe
(@130 cd setting)
×
0.0000045
0.164
FW962R/FW962W
(@105 cd setting)
Multi-candela Horn Strobe
(@105 cd setting)
×
0.0000045
0.126
FW962R/FW962W
(@85 cd setting)
Multi-candela Horn Strobe
(@85 cd setting)
×
0.0000045
0.085
FW962R/FW962W
(@50 cd setting)
Multi-candela Horn Strobe
(@50 cd setting)
×
0.0000045
0.055
FW962R/FW962W
(@35 cd setting)
Multi-candela Horn Strobe
(@35 cd setting)
×
0.0000045
0.047
FW962R/FW962W
(@20 cd setting)
Multi-candela Horn Strobe
(@20 cd setting)
×
0.0000045
0.030
FW982R/FW982W
(@130 cd setting)
Multi-candela Strobe
(@130 cd setting)
×
0.0000045
0.156
FW982R/FW982W
(@105 cd setting)
Multi-candela Strobe
(@105 cd setting)
×
0.0000045
0.119
FW982R/FW982W
(@85 cd setting)
Multi-candela Strobe
(@85 cd setting)
×
0.0000045
0.080
FW982R/FW982W
(@50 cd setting)
Multi-candela Strobe
(@50 cd setting)
×
0.0000045
0.049
FW982R/FW982W
(@35 cd setting)
Multi-candela Strobe
(@35 cd setting)
×
0.0000045
0.043
FW982R/FW982W
(@20 cd setting)
Multi-candela Strobe
(@20 cd setting)
×
0.0000045
0.028
FW972MR/FW972
MW(@ low setting)
Mini Horn
x
0
0.008
FW972MR/FW972
MW(@ medium
setting)
Mini Horn
x
0
0.008
