Installation and Operation Manual
56
FW972MR/FW972
MW(@ high
setting)
Mini Horn
x
0
0.015
FW963A(R/W)
(@177 cd)
Addressable Horn Strobe
0
0.218
FW963A(R/W)
(@130 cd)
Addressable Horn Strobe
0
0.164
FW963A(R/W)
(@100cd)
Addressable Horn Strobe
0
0.129
FW963A(R/W)
(@75 cd)
Addressable Horn Strobe
0
0.098
FW963A(R/W)
(@45 cd)
Addressable Horn Strobe
0
0.07
FW963A(R/W)
(@15 cd)
Addressable Horn Strobe
0
0.055
FW973A(R/W)
Addressable Horn
0
0.048
FW983A(R/W)
(@177 cd)
Addressable Strobe
0
0.21
FW983A(R/W)
(@130 cd)
Addressable Strobe
0
0.145
FW983A(R/W)
(@100cd)
Addressable Strobe
0
0.114
FW983A(R/W)
(@75 cd)
Addressable Strobe
0
0.084
FW983A(R/W)
(@45 cd)
Addressable Strobe
0
0.055
FW983A(R/W)
(@15 cd)
Addressable Strobe
0
0.04
Miscellaneous (All currents are in ampere)
EOL
×
0.00082
0.00082
Auxiliary Power Supply
Standby
Alarm
Total Currents
Standby
Alarm
