DESKTOP PRINTER SERVICE MANUAL
REPLACING THE BEAGLEBONE
QService Notes (p.4).
Note: Take care not to discard any hardware you remove during this procedure, as you will need it
during the reinstallation.
Tools
● 2mm hex key
● Phillips #1 screwdriver
● Painter’s tape (or similar tape that will not leave residue on the printer)
● Small zip tie
● Wire cutters or similar tool
BEAGLEBONE REMOVAL
1. Unloading Plastic and Unloading
Fiber, if applicable, in the User Guide.
2.
3.
4.
5. Disconnect the feed tube from the plastic extruder. Remove it from the printer and set it aside.
6. Tape the lid and visor of the printer closed to prevent them from accidentally opening.
7. Carefully turn the printer upside down so that the bottom is facing up and the rear of the printer is facing
toward you.
8.
9. Remove and set aside the bottom panel.
