Masibus LC5296-XP User Manual

Model: LC5296-XP-AT / LC5296-XP/LC5296-XP-I
Doc. Ref. no. :- m61D/om/101
Issue no. 17
User’s Manual Page 19 of 56
 Shows %Power value if Device is in Auto
Mode during RUN mode. (for LC5296-XP-
AT Only)
 In Manual Mode this key is used to
Decrement the %Power. (for LC5296-XP-AT
Only)
SET Key
(Menu /
Enter Key)
 Shows Different Set Point, if this pressed in
RUN mode.
 It is used to enter in the sub menu (TUNE,
CONF, CAL)
 In Sub Menu it can be used to get to the
next Parameter.
 It is also used to save the parameters to
nonvolatile memory, when user setting a
proper data by Increment and decrement
key for parameter configuration.



Escape
Key
 Get to the Previous Menu level.



Auto/Manu
al Key
 It is used to switch between Auto to Manual
mode and Manual to Auto mode if pressed
for at least 2 sec in case of F.key in CONF
menu is selected A-Morramp is none.
 If Ramp is not none and F.key in CONF
menu is selected sok.t then it will display
remaining time



PV
(Process
Value)
Display
PV
 4 digital 0.56 inch RED Display
 Display process value.
 Display parameter name when user set
parameter.
 Display error message when an error
occurs.



SV
(Set Value)
Display
SV
 4 digital 0.4 inch GREEN
 Display set value.
 Display parameter value of parameter in
process value field when user set
parameter.
 Display control output value when in manual
mode.



Relay-1
Indication
RL1
 ON when Relay-1 is energized & OFF
otherwise.



Relay-2
Indication
RL2
 ON when Relay-2 is energized & OFF
otherwise.



SSR
Indication
SSR
 SSR ON status.



MANUAL
Indication
MAN
 ON when unit is in Manual mode.
 OFF when unit in Auto Mode.



TX
Tx
 ON when device is transmitting some Data



