Masibus LC5296-XP User Manual

Model: LC5296-XP-AT / LC5296-XP/LC5296-XP-I
Doc. Ref. no. :- m61D/om/101
Issue no. 17
User’s Manual Page 45 of 56
9. ALARM OUTPUT
Available Only for LC5296-XP-AT
For all Alarm outputs there are five settings. (As shown in configuration mode Menu)
 Set Value (in run mode)
 Type
 Hysteresis(Dead band)
 Direction (Normal/Fail safe)
 Delay
SET VALUE: Alarm set point
9.1 ALARM TYPES
Various alarm operations are shown in the reference figure.
ALARM
TYPE
NO
Display
message
ALARM TYPE
Note
0
none
None
NO operation available
1
Pv.d.H
Deviation High alarm
Ref figure 3
2
Pv.d.l
Deviation Low alarm
Ref figure 4
3
Pv.d.r
Deviation High & Low range alarm
Ref figure 5
4
Pv.d.b
Deviation High & Low Band alarm
Ref figure 6
5
Pv.a.H
Absolute value High alarm
Ref figure 1
6
Pv.A.L
Absolute value Low alarm
Ref figure 2
7
SP.A.H
Absolute value set point high alarm
Ref figure 7
8
SP.A.L
Absolute value set point low alarm
Ref figure 8
9
P.S.d.H
Deviation High alarm with standby
Same as figure 3
10
P.S.d.L
Deviation Low alarm with standby
Same as figure 4
11
P.S.d.r
Deviation High & Low range alarm with standby
Same as figure 5
12
P.S.d.b
Deviation High & Low limit alarm with standby
Same as figure 6
13
P.S.A.H
Absolute value High alarm with standby
Same as figure 1
14
P.S.A.L
Absolute value Low alarm with standby
Same as figure 2
15
PV.-E.
PV error(OPEN/OVER/UNDER)
Note 1
NOTE-1:
The fault diagnosis output turns on in case of input burnout (PV) failure.
