Masibus LC5296-XP User Manual

Model: LC5296-XP-AT / LC5296-XP/LC5296-XP-I
Doc. Ref. no. :- m61D/om/101
Issue no. 17
User’s Manual Page 55 of 56
DOWN
DIR
4.0
20.0
4.0
SSR
Pulse Output
UP
DIR
ON
ON
OFF
DOWN
REV
OFF
OFF
ON
UP
REV
ON
OFF
ON
DOWN
DIR
OFF
ON
OFF
RELAY
UP
DIR
ON
ON
OFF
DOWN
REV
OFF
OFF
ON
UP
REV
ON
OFF
ON
DOWN
DIR
OFF
ON
OFF
12.5 Jumper Settings for Addon Card Selection &RetransmissionOutput
Type
 Thesedevicescome with different Variants differing by various Output option
available.
 There are Two Addon Card Slots available on PCB of Signal Card. The Right
Most Slot is fixed for Retransmission (Analog) Output. And the other Left Slot
can be used for either Retransmission or RS-485 Communication Card by
appropriate Jumper setting shown in below figure.
 0E (SMD 0805) Resistor is used for shorting the Jumper.
 There are mainly Two types of Retransmission Output is available:
o Voltage (0-10VDC, 0-5VDC, 1-5VDC)
o Current (4-20mADC, 0-20mADC)
 This can be Settable by changing the Position of Shorting Link Jumpers on
Retransmission Addon Card shown in below figure.
 Jumper Setting for Retransmission card: m61Cao201
