6.6 *SETPARAMODE
*only shows if SP.PW is Yes in configuration mode
NOTE:-
The retransmission output type is jumper selectable. Thus if current type or
voltage type output, will be decided by the position of the jumper.
The Linear type control output will depend on the type of
Retransmission-1 output selection. If Retransmission-1 type output is 4-
20mA, then the linear output will function respectively.
No need to feed input while calibrating Rx. o/p. just make the value in
calibration mode equal to the displayed value.
Example: How to Change Input Type?
RTS2
(rts2)
Retransmission-2
SPAN
Calibration Span for
Retransmission Output-2
(SV Display : If voltage: 8.000
If Current: 20.00)
-
Device
Supports
Dual
Retransmission
Output
Set Point Setting:
Parameter
(PV display)
Setting name and
description
Default
value
Shows only
if
Symbol
Name
C1SP
(C1sp)
Control Set Point 1
Range Depending on PV
sensor type selected
100
-
A1SP
(A1sp)
Alarm Set Point 1
Range Depending on PV
sensor type selected
100
Output Type is
LIN(Linear)
A2SP
(A2sp)
Alarm Set Point 2
Range Depending on PV
sensor type selected
100
-
