Masibus LC5296-XP - Communication Details; Power Supply; Environmental Conditions; Special Feature

Model: LC5296-XP-AT / LC5296-XP/LC5296-XP-I
Doc. Ref. no. :- m61D/om/101
Issue no. 17
User’s Manual Page 9 of 56
2.4 Communication Details
Communication
Interface
RS485 (2 Wire)
Protocol
Modbus-RTU
Baud rate
9600, 19200, 38400 bps
2.5 Power Supply
Standard
85-265VAC/ 100-300VDC
Optional
18-36VDC
Power consumption
<10 VA
Data backup
Non-volatile memory (can be written up to 100000 times)
 Isolation (Withstanding voltage)
 Between primary terminals* and secondary terminals**:
At least 1500 V AC for 1 minute
 Between primary terminals* and grounding terminal:
At least 1500 V AC for 1 minute
 Between grounding terminal and secondary terminals**:
At least 1500 V AC for 1 minute
 Between secondary terminals**:
At least 500 V AC for 1 minute
* Primary terminals indicate power terminals and relay output terminals.
** Secondary terminals indicate analog I/O signal and Communication O/P.
 Insulation resistance:20MΩ or more at 500 V DC between power terminals and
grounding terminal.
2.6 Environmental Conditions
TEMPCO
For Input to PV Display < 100ppm. FOR Display to
Retransmission and Control output < 100ppm
Humidity
30% to 95% RH (Non-Condensing)
Instrument Warm-up Time
Approx. 15 minutes
Ambient temperature
0 to 55°C
Storage Temperature
0 to 80°C
2.7 Special Feature
1. Input Scalability for Linear Input type(only for LC5296-XP and LC5296-XP-I model)
2. Ramp Soak Function (only for LC5296-XP-AT)
