Masibus LC5296-XP User Manual

Model: LC5296-XP-AT/LC5296-XP/LC5296-XP-I
Doc. Ref. no.:- m61D/om/101
Issue no. 17
User’s Manual Page 8 of 56
Relay Output
Relays
1 (For LC5296-XP-AT)
2 (For LC5296-XP)
Optional For LC5296-XP-I
Type
Single Change over
Three Terminals (C, NO, NC)
Rating
2A @ 230VAC / 30VDC
Pulse Output (SSR)(For LC5296-XP-AT Only)
Output signal
Voltage Pulse Output
Output signal On-condition
11VDC or more
Off-condition
2VDC or less
Resolution
10 ms
Linear Output (For LC5296-XP-AT Only)
Output Signal
Voltage (0-5VDC, 1-5VDC, 0-10VDC) @3kΩ Min
Current (4-20mADC, 0-20mADC) @500Ω Max
Retransmission Output
Number of output
1 (@Retransmission-2)(For Linear Output Type) or
2 (@Retransmisswion-1&2)(For Relay 0r SSR Output
Type)
Output According to
Process Value
Output Signal
4-20mA / 0-20mA /1-5VDC / 0-5VDC / 0-10V DC
Load resistance
 For Current o/p
 For Voltage o/p
< 500Ω
> 3KΩ
Output accuracy
±0.25% of span
Alarm Output (For LC5296-XP-AT Only)
Number of Outputs
2 if Output Type is Linear(@Relay-1&2),
1 if Output Type is Relay or SSR(@Relay-2)
Control relays are available as alarm outputs
Output signal
Three terminals (NC, NO, and C)
Purpose
Alarm output and others.
(See Alarm and Digital outputs function)
Relay contact rating
250 V AC or 30 V DC, 2A (resistive load)
Loop Power Supply
Supply Voltage
24VDC (±1V) @26mA with Inbuilt Short Circuit
Protection
Minimum load resistance
800 ohms
