Masibus LC5296-XP User Manual

Model: LC5296-XP-AT/LC5296-XP/LC5296-XP-I
Doc. Ref. no.:- m61D/om/101
Issue no. 17
User’s Manual Page 38 of 56
7.4 CALIBRATION MODE
RTR.2
(rtr.2)
Retransmission
2 Type
Retransmission-2 Output Type
This output is according to PV input.
Zero & Span acts as Min & Max value of
retransmission o/p scale respectively.
0-5v / 1-5v / 0-10v / 4-20 / 0-20
0 : 0-5V
1 : 1-5V
2 : 0-10V
3 : 4-20mA
4 : 0-20mA
Voltage or Current is Jumper Selectable
from the Hardware.
4-20
Device
Supports Dual
Retransmissio
n Output.
RT.D.2
(rt.d.2)
Retransmission
-2 Direction
Set Direction for the
Retransmission Output-2
rev / dir
0 : REV (REVERSE)
1 : DIR (DIRECT)
DIR
Device
Supports Dual
Retransmissio
n Output.
A.CJC
(a.CJC)
Auto
ColdJunction
Compensation
Select Auto Cold Junction Compensation
required or not for TC input Type.
no / yes
0 : NO
1 : YES
YES
Input Type is
TC
F.CJC
(F.CJC)
Fix cold
junction
Compensation
Set Fix cold junction Compensation value.
0 to 60.0 °C
0.0
Input Type is
TC & A.CJC is
NO
VER
(ver)
Version
Shows the Version of the Current Firmware
-
PASS
(pass)
Password
Set Device Password
0 to 9999
1
CALIBRATION PARAMETERS
Parameter
(PV display)
Setting Name & Description
Default
Value
Show if Only
Symbol
Name
AMB
(Amb)
Ambient
Ambient Adjustment
-
Input is TC
ZERO
(zero)
ZERO
Calibration Zero for PV Input
(SV Display : PV)
-
SPAN
(span)
SPAN
Calibration Span for PV Input
(SV Display : PV)
-
