Masibus LC5296-XP User Manual

Model: LC5296-XP-AT / LC5296-XP/LC5296-XP-I
Doc. Ref. no. :- m61D/om/101
Issue no. 17
User’s Manual Page 37 of 56
SR.NO
(sr.no)
Serial No.
Unit ID for Modbus-RS485 Communication
1 to 247
1
Device
supports
RS485
Communicatio
n.
BAUD
(baud)
Baud Rate
Set Modbus RS485 Communication Baud
Rate
9600 / 19.2k / 38.4k
0 : 9600 (9600 bps)
1 : 19.2K (19200 bps)
2 : 38.4K (38400 bps)
9600
Device
supports
RS485
Communicatio
n.
RTR.1
(rtr.1)
Retransmission
1 Type
Retransmission-1 Output Type
This output is according to PV input.
Zero & Span acts as Min & Max value of
retransmission o/p scale respectively.
0-5v / 1-5v / 0-10v / 4-20 / 0-20
0 : 0-5V
1 : 1-5V
2 : 0-10V
3 : 4-20mA
4 : 0-20mA
Voltage or Current is Jumper Selectable
from the Hardware.
4-20
Device
Supports
Retransmissio
n Output.
RT.D.1
(rt.D.1)
Retransmission
-1 Direction
Set Direction for the
Retransmission Output-1
rev / dir
0 : REV (REVERSE)
1 : DIR (DIRECT)
EX. If i/p is RTD.1, ZERO=0, SPAN=600,
RTR.1=4-20mA &
RT.D.1=DIR
when PV = 0, RTR o/p = 4mA
PV = 300, RTR o/p = 12mA
PV = 600, RTR o/p = 20mA
RT.D.1=REV
when PV = 0, RTR o/p = 20mA
PV = 300, RTR o/p = 12mA
PV = 600, RTR o/p = 4mA
Refer Retransmission o/p table on Page 54 for
more info.
DIR
Device
Supports
Retransmissio
n Output.
